Full-tower chassis with two modes: Normal Mode/ Reverse Mode
-
Front and side tempered glass panels with a removable pilar for a seamless view of components and RGB lighting
-
Supports up to 3x 420mm radiators and a maximum of 11 fans
-
Offers mounting space for 7 storage drives
-
Dual-chamber layout with cable management compartment and three cable holders
-
Features a multi-directional power button and movable IO module
-
Optional accessories for vertical GPU or upright GPU mounting
| PRODUCT NAME | O11D EVO XL | |
|---|---|---|
| CASE TYPE | Tower Chassis | |
| MODEL | O11DEXL-X | O11DEXL-W |
| COLOR | Black | White |
| DIMENSIONS | (D) 522mm x (W) 304mm x (H) 531.9mm | |
| MATERIAL | Steel 4.0mm Tempered Glass Aluminum |
|
| MOTHERBOARD SUPPORT | E-ATX (Under 280mm)/ATX/Micro-ATX/Mini-ITX | |
| EXPANSION SLOT | 8 | |
| STORAGE | Behind MB Tray: 3 x 2.5” SSD Hard Drive Cage: 4 x 3.5” HDD / 2.5” SSD |
|
| GPU LENGTH CLEARANCE | 460mm (Max.) | |
| CPU COOLER HEIGHT CLEARANCE | 167mm (Max.) | |
| PSU | ATX (Under 220mm) | |
| FAN SUPPORT | Top: 3 x 120mm / 3 x 140mm Side: 3 x 120mm / 3 x 140mm Bottom: 3 x 120mm / 3 x 140mm Rear: Up to 2x 120mm |
|
| RADIATOR SUPPORT | Top: 360 / 420 / 240 / 280mm Side: 360 / 420 / 240 / 280mm Bottom: 360 / 420 / 240 / 280mm |
|
| I/O PORTS | 1 x Power Button 1 x Reset Button 4 x USB 3.0 1 x USB Type C 1 x Audio 1 x LED Color Button 1 x LED Mode Button |
|
| DUST FILTERS | 1 x Bottom 1 x Top 2 x Side |
|
| WARRANTY | 1 year | |
