ASUS Advanced BTF Series - ROG Series Gaming PC Package (FREE-ROG Strix XG27ACS 27" USB Type-C Gaming Monitor)

ASUS Advanced BTF Series - ROG Series Gaming PC Package (FULL HIDDEN-CONNECTORS DESIGN)

PC SPECIFICATION:

• Intel Core i9-14900K
• 2TB Gen4 M.2 SSD SAMSUNG 980 PRO
• 32GB 6400Mhz DDR5 CORSAIR RGB
• 1x ASUS ROG THOR 1000W PSU
• 1x ASUS ROG RYUJIN III ARGB 360 Liquid Cooler
• 1x ROG MAXIMUS Z790 HERO BTF
• 1x ROG Strix GeForce RTX™ 4090 BTF OC 24GB GDDR6X
• 1x ROG Hyperion GR701 BTF Edition EATX Case
• 1x ASUS ROG Strix XG27ACS USB Type-C Gaming Monitor [FREE]

BTF (Back-To-The-Future) - ASUS Hidden-Connector Design

ASUS BTF DESIGN
ASUS is driven to innovate, and we are constantly exploring and experimenting with technology to deliver better experiences to everyone. With this user-centric approach, ASUS has launched the Back-To-the-Future (BTF) series of products and solutions. BTF represents a new direction that will lead the future of DIY. It symbolizes our goal of providing users with more aesthetically pleasing PC assembly by hiding connectors on the underside of a motherboard, leading to cleaner cable management and a more minimalist appearance.

ADVANCED BTF
With the combination of a BTF graphics card, motherboard, and chassis, you can enjoy a full hidden-connector experience. This Advanced BTF approach is achieved through PCIe high-power connector on the BTF graphics cards compatible with the new graphics card high-power slot available on BTF motherboards. With a set of compatible BTF components, builders can eliminate the need for visible cables for a clean and organized Advanced BTF look.

ASUS ROG ADVANCED BTF PRODUCTS

01) ROG MAXIMUS Z790 HERO BTF (NEW)

ROG Maximus Z790 Hero BTF is the first ROG motherboard with a hidden-connector design and graphics card high-power slot that delivers up to 600 watts of power for BTF graphics cards through the motherboard, providing an unprecedented level of cable management to PC DIY enthusiasts. It also boasts robust cooling, WiFi 7 and ample PCIe^® 5.0 slots for unmatched performance, plus full compatibility with 14^th Gen Intel^® Core™ processors.

• HIDDEN-CONNECTOR DESIGN - For clean cable management
• GRAPHICS CARD HIGH-POWER SLOT - Delivering up to 600 watts through the motherboard
• DIY-FRIENDLY DESIGN
• EXTENSIVE GEN 5 - x1 onboard M.2 slot, and x1 PCIe 5.0 x16 slot
• MAX. 192GB, DIMM FLEX, AEMP II
• WIFI 7
• AI OVERCLOCKING - Effortless performance boost
• AI COOLING II - One-click fan tuning
• TEAMED POWER SOLUTION
• POLYMO LIGHTING



02) ROG Strix GeForce RTX™ 4090 BTF OC Edition 24GB GDDR6X (NEW)

ROG Strix GeForce RTX™ 4090 BTF OC Edition 24GB GDDR6X buffed-up design with chart-topping thermal performance and innovative Graphics Card High-Power (GC-HPWR) Gold Finger.

• Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing
• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2x ray tracing performance
• OC edition: boost clock 2640 MHz (OC mode)/ 2610 MHz (default mode)
• Graphics card high-power gold finger for power transmission, and prevent GPU sag
• Eliminate the need for traditional 16-pin external power connections to the graphics card
• Axial-tech fans scaled up for 23% more airflow
• New patented vapor chamber with milled heatspreader for lower GPU temps
• 3.5-slot design: massive fin array optimized for airflow from the three Axial-tech fans
• Diecast shroud, frame, and backplate add rigidity and are vented to further maximize airflow and heat dissipation
• Digital power control with high-current power stages and 15K capacitors to fuel maximum performance
• Auto-Extreme precision automated manufacturing for higher reliability
• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring



03) ROG Hyperion GR701 BTF Edition E-ATX Case (NEW)

ROG Hyperion GR701 BTF Edition E-ATX computer case, motherboard hidden connectors design support, 420 mm dual radiator support, four 140 mm fans, metal GPU holder, component storage, ARGB fan hub, 60W fast charging.

• Extra Clean: Supports Motherboard’s hidden connectors design by having virtually no wire and cluttering.
• Extra Cooling: Dual 420mm radiator support, four 140 mm fans and a built-in fan hub offer massive airflow possibilities
• Extra Space: The beefiest graphics cards get plenty of room; cable management gets an expansive chamber that is 34 mm deep, with a 46 mm wide routing channel
• Extra Convenience: Hinged tool-free side panels, a built-in storage drawer and an integrated graphics card holder come together to amp up the building experience
• Extra Power: Dual USB Type-C ports, 60-watt fast charging, aluminum-reinforced frame and handles deliver power and premium ruggedness



PRODUCT SPECIFICATIONS

01) ROG MAXIMUS Z790 HERO BTF

Model: ROG MAXIMUS Z790 HERO BTF
CPU: Intel^® Socket LGA1700 for Intel^® Core™ 14^th & 13^th Gen Processors, Intel^® Core™ 12^th Gen, Pentium^® Gold and Celeron^® Processors
Supports Intel^® Turbo Boost Technology 2.0 and Intel^® Turbo Boost Max Technology 3.0**

* Refer to www.asus.com for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset: Intel^® Z790 Chipset
Memory:
• 4 x DIMM slots, max. 192GB, DDR5
 • 8000+(OC)/7800 (OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory*
• Dual channel memory architecture
• Supports Intel^® Extreme Memory Profile (XMP) memory module
• Supports DIMM Flex
• ASUS Enhanced Memory Profile II (AEMP II)

* Supported memory types, data rate (Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Graphics:
• 1 x HDMI^TM port**
• 2 x Intel^® Thunderbolt™ 4 ports (USB Type-C^®) support DisplayPort and Thunderbolt™ video outputs***

* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Support 4K@60Hz as specified in HDMI 2.1.
*** VGA resolution support depends on processors' or graphic cards' resolution.

Expansion Slots:
Intel^® Core^TM Processors (14t^h & 13^th & 12^th Gen)*
• 1 x PCIe 5.0 x16 slot (support x16 or x8 modes)**
Intel^® Z790 Chipset
• 1 x PCIe 4.0 x4 slot

* Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
** When M.2_1 is enabled, PCIEX16(G5)_1 will run x8 only.
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.

Storage Supports:
Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel^® Core^TM Processors (14^th & 13^th & 12^th Gen)
• M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode.)**
• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode.)
Intel^® Z790 Chipset**
• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
• M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
• M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
• 4 x SATA 6Gb/s ports

* Intel^® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.
** When M.2_1 is enabled, PCIEX16(G5)_1 will run x8 only.

Ethernet:
• 1 x Intel^® 2.5Gb Ethernet
• ASUS LANGuard

Wireless & Bluetooth:
• Intel^® Wi-Fi 7*
• 2x2 Wi-Fi 7 (802.11be)**
• Supports 2.4/5/6GHz frequency band***
• Support Wi-Fi 7 320MHz bandwidth, up to 5.76Gbps transfer rate.
• Bluetooth^® v5.4****

* Compatible with Windows 11 or later.
** Wi-Fi 7 MLO(Multi-link Operation) full functions support will be ready in Windows 11 2024 Platform (Windows 11 24H2) or later.
*** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
**** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.

USB:
Rear USB (Total 12 ports)
• 2 x Thunderbolt™ 4 ports (2 x USB Type-C^®)
• 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C^®)
• 4 x USB 5Gbps ports (4 x Type-A)
Front USB (Total 9 ports)
• 1 x USB 20Gbps connector
• 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
• 2 x USB 2.0 headers support 4 additional USB 2.0 ports

Audio Features
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
Audio Features
- SupremeFX Shielding Technology
- ESS^® ES9218 QUAD DAC
- Gold-plated audio jacks
- Rear optical S/PDIF out port
- Premium audio capacitors

* The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.

Back Panel I/O Ports:
2 x Thunderbolt™ 4 USB Type-C^® ports
6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C^®)
4 x USB 5Gbps ports (4 x Type-A)
1 x HDMI^TM port
1 x Wi-Fi Module
1 x Intel^® 2.5Gb Ethernet port
5 x Gold-plated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™  button
1 x Clear CMOS button

Internal I/O Connectors:
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
1 x W_PUMP+ header
Power related
1 x 24-pin main power connector
2 x 8-pin +12V power connector
1 x Graphics card high power slot
1 x 12V-2X6 Auxiliary power connector
Storage related
5 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C^®)
2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x AURA RGB header
1 x FlexKey button
1 x Front panel audio header (F_AUDIO)
1 x Start button
1 x 10-1 pin system panel header
1 x Thermal sensor header
1 x Q-Installation Switch

Special Features:
Extreme OC Kit
- FlexKey button
- Start button
Extreme Engine Digi+
- 10K Black metallic capacitors
- MicroFine alloy choke
ASUS Q-Design
- M.2 Q-Latch
- PCIe Slot Q-Release Slim
- Q-Antenna
- Q-Code
- Q-Connector
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) with DRAM Detection
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- Clear CMOS button
- CPU Socket lever protector
- ProCool II
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
AURA Sync
- AURA RGB header(s)
- Addressable Gen 2 header(s)

Software Features:
ROG Exclusive Software
- ROG CPU-Z
- DTS^® Sound Unbound
- Internet Security (1 year full version)
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (1 year full version)
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- GameFirst
- Two-Way AI Noise Cancelation
- Power Saving
- Sonic Studio
AI Suite 3
- Easy Optimization with AI Overclocking
- TPU
- DIGI+ Power Control
- Turbo app
- PC Cleaner
MyAsus
Intel^® Unison™
Adobe Creative Cloud (Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
MemTest86

BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
Manageability: WOL by PME, PXE

Accessories:
Cables
1 x ARGB RGB extension cable
4 x SATA 6Gb/s cables
Additional Cooling Kit
1 x Thermal pad for M.2
1 x DDR5 fan holder
Miscellaneous
1 x ASUS WiFi Q-Antenna
3 x M.2 backplate Q-Latch packages
3 x M.2 backplate Rubber Packages
1 x Q-connector
1 x ROG stickers
1 x ROG key chain
1 x M.2 rubber package
1 x ROG VIP card
Installation Media
1 x USB drive with utilities and drivers
Documentation
1 x Quick start guide

Operating System: Windows^® 11, Windows^® 10 64-bit
Form Factor: ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

02) ROG Strix GeForce RTX™ 4090 BTF OC Edition 24GB GDDR6X

Model: ROG Strix GeForce RTX™ 4090 BTF OC Edition 24GB GDDR6X
Graphic Engine: NVIDIA^® GeForce RTX™ 4090
Bus Standard: PCI Express 4.0
OpenGL: OpenGL^®4.6
Video Memory: 24GB GDDR6X
Engine Clock: OC mode: 2640 MHz / Default mode: 2610 MHz (Boost clock)
CUDA Core: 16384
Memory Speed: 21 Gbps
Memory Interface: 384-bit
Resolution: Digital Max Resolution 7680 x 4320
Interface: Yes x 2 (Native HDMI 2.1a) / Yes x 3 (Native DisplayPort 1.4a) / HDCP Support Yes (2.3)
Maximum Display Support: 4
NVlink/ Crossfire Support: No

Accessories:
1 x Collection Card​, 1 x Speedsetup Manual​, 1 x ROG Graphics Card Holder, 1 x ROG Velcro Hook & Loop & 1 x Thank you Card

Software:
ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.

Dimensions: 357.6 x 149.3 x 70.1mm
Recommended PSU: 1000W
Power Connectors: PCIe high-power connector
Slot: 3.5 Slot
AURA SYNC: ARGB
Hidden-Connector (BTF): With Graphics card high-power gold finger

Note: * BTF edition graphics cards are designed for use only with advanced BTF motherboards (which have Graphics Card High-Power Slot).
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
* All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products.

03) ROG Hyperion GR701 BTF Edition E-ATX Case

Model: ROG Hyperion GR701 BTF Edition
Motherboard Support:EATX (12"x10.9"), ATX, Micro-ATX, Mini-ITX
Drive Bays: 5 x 2.5" Bay, 2 x 2.5"/3.5" Combo Bay
Expansion Slots: 9 , 3 (additional vertical)
Front I/O Port: 1 x headphone / Microphone, 4 x USB 3.2Gen1, 1 x USB 3.2 Gen2 Type C,
LED Control Button, Reset Button, 1 x USB 4.0 Type C or 1 x USB 3.2 Gen 2x2 Type C (* This spec might vary by region)
Tempered Glass: Left Side / Right Side
Radiator Support (Front): 120 mm / 140 mm / 240 mm / 280 mm / 360 mm / 420 mm
Radiator Support (Top): 120 mm / 140 mm / 240 mm / 280 mm / 360 mm / 420 mm
Radiator Support (Rear): 120 mm / 140 mm
Cooling Support (Front): 3 x 120 mm / 3 x 140 mm
Cooling Support (Top): 3 x 120 mm / 3 x 140 mm
Cooling Support (Rear): 1 x 120 mm / 1 x 140 mm
Pre-installed Fans (Front): 3 x 140 mm / PWM
Pre-installed Fans (Rear): 1 x 140 mm / PWM
Maximum CPU Cooler Height: 190 mm
Maximum GPU Length: 460 mm
Maximum PSU Length: 240 mm
Removable Dust Filters: Front / Top / Bottom
Maximum Cable Management Space: 34 mm
Dimensions: 268 * 639 * 659 mm
Weight: 21.3 Kg (GR701 BTF Edition)
AURA Sync: ARGB

• Products certified by the Federal Communications Commission and Industry Canada will be distributed in the United States and Canada. Please visit the ASUS USA and ASUS Canada websites for information about locally available products.
• All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
• Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.
• PCB color and software versions are subject to change without notice.
• Brand and product names mentioned are trademarks of their respective companies.
• Unless otherwise stated, all performance claims are based on theoretical performance. Actual figures may vary in real-world situations.
• The actual transfer speed of USB 3.0, 3.1, 3.2, and/or Type-C will vary depending on many factors including the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment.
