11 Gbps Tri-Band WiFi – 5760 Mbps(6 GHz) + 4320 Mbps(5 GHz) + 574 Mbps(2.4 GHz).†
-
2.5 Gbps Wired Connections – 4× 2.5 Gbps ports ensure max flexibility and boosted throughput.§
-
Wireless and Wired Combined Backhaul – Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency.
-
Multi-Link Operation (MLO) – Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability.△
-
320 MHz Channels – Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds.△
-
Works on the 6 GHz Band – Minimizes congestion with greenfield spectrum, delivering robust high-speed connections.△
-
TP-Link HomeShield – Provides comprehensive network protection, robust parental controls, and real-time IoT security.*
-
Universal Compatibility – Backward compatible with all WiFi generations and works with any internet service provider (ISP) and modem.☆
tp-link
TP-LINK Deco BE65 (3-Pack) BE11000 Tri-Band Whole Home Mesh Wi-Fi 7 System 4x 2.5Gbps, Wireless & Wired Combined, Multi-Link Operation, 320 MHz Channel, Universal Compatibility
TP-LINK Deco BE65 (3-Pack) BE11000 Tri-Band Whole Home Mesh Wi-Fi 7 System 4x 2.5Gbps, Wireless & Wired Combined, Multi-Link Operation, 320 MHz Channel, Universal Compatibility
Couldn't load pickup availability
TP-LINK Deco BE65 (3-Pack) BE11000 Tri-Band Whole Home Mesh Wi-Fi 7 System
4x 2.5 Gbps, Wireless & Wired Combined, Multi-Link Operation, 320 MHz Channel, Universal Compatibility
SPECIFICATIONS
WIRELESS
STANDARDS
• Wi-Fi 7
- IEEE 802.11be/ax 6 GHz
- IEEE 802.11be/ax/ac/n/a 5 GHz
- IEEE 802.11ax/n/b/g 2.4 GHz
WIFI SPEEDS
• BE11000
- 6 GHz: 5760 Mbps (802.11be)
- 5 GHz: 4320 Mbps (802.11be)
- 2.4 GHz: 574 Mbps (802.11ax)
WIFI RANGE
• Broader Whole Home Coverage
- TP-Link Mesh Technology: Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
- AI-Driven Mesh: Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
- 4× High-Performance Antennas (Internal): Multiple antennas form a signal-boosting array to cover more directions and large areas
- Tri-Band: A newly-opened 6 GHz band brings more bandwidth and faster speeds
WIFI CAPACITY
• Very High
- Tri-Band: Distribute devices to different bands for optimal performance
- 2×2 MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients
- OFDMA: Simultaneously communicates with multiple WiFi 7 clients
- 6 Streams: More than enough bandwidth for connected devices
WORKING MODES
• Router Mode
• Access Point Mode
ADVANCED FUNCTIONS
• Multi-Link Operation (MLO)
• 320 MHz Channel
• 4K-QAM
• Multi-RUs
• Works with Alexa and Google Assistant
SECURITY
NETWORK SECURITY
• SPI Firewall
• Access Control
• HomeShield Security
- Real-Time IoT Protection
- Malicious Site Blocker
- Intrusion Prevention System
- DDoS Attack Prevention
- Home Network Scanner
GUEST NETWORK
• 1× 6 GHz Guest Network
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
- Effective Time
- Bandwidth Control
VPN SERVER
• OpenVPN Server
• PPTP VPN Server
• L2TP/IPSec VPN Server
VPN CLIENT
• OpenVPN Client
• PPTP VPN Client
• L2TP/IPSec VPN Client
WIFI ENCRYPTION
• WPA-Personal
• WPA2-Personal
• WPA3-Personal
HARDWARE
ETHERNET PORTS
• 4× 2.5 Gbps
*Per Deco Unit
• Supports WAN/LAN auto-sensing
USB SUPPORT
• 1× USB 3.0 Port
- FTP Server
- Media Server
- Apple Time Machine
- Samba Server
BUTTONS
• 1× Reset Button
• 1× WPS
SOFTWARE
ADVANCED FEATURES
• Reboot Schedule
• Tapo/Kasa Onboarding
• IoT network & Device Isolation
• Static Routing Function
• Node/Band Connection Preference
PROTOCOLS
• IPv4
• IPv6
SERVICE KITS: HomeShield
PARENTAL CONTROLS
• HomeShield Parental Controls
- Youtube Restriction
- SafeSearch
- Custom Profiles
- Professional Content Filter Library
- Family Time
- Bedtime
- Off Time
- Time Rewards
- Family Online Time Ranking
- Pause the Internet
- Weekly and Monthly Reports
WAN TYPES
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP
QUALITY OF SERVICE
HomeShield QoS: QoS by Device
CLOUD SERVICE
• OTA Firmware Upgrade
• TP-Link ID
• DDNS
NAT FORWADING
• Port Forwarding
• UPnP
IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN
DHCP
• Address Reservation
• DHCP Client List
• Server
DDNS: TP-Link
MANAGEMENT: Deco App
PHYSICAL
DIMENSIONS (WxDxH): 4.23 × 4.23 × 6.93 in (107.5 × 107.5 × 176 mm)
PACKAGE CONTENTS
Deco BE65(3-pack)
• 3 Deco BE65 units
• 1 RJ45 Ethernet cable
• 3 Power adapters
• Quick Installation Guide
OTHERS
CERTIFICATIONS: CE, FCC, RoHS
ENVIRONMENT
• Operating Temperature: 0°C~40°C (32 °F~104 °F)
• Storage Temperature: -40°C~60°C (-40 °F~140 °F)
• Operating Humidity: 10%~90% RH
• Storage Humidity: 5%~90% RH
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Connection to over 200 devices is based on laboratory test data, which analyzed the connections of different devices on the 6 GHz, 5 GHz, and 2.4 GHz bands simultaneously. These devices simulated a typical home scenario by running simultaneous applications in the same room that included 4K video, 1080p video, 720p video, file downloading, web browsing, IP cameras, and other IoT devices. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
‡Clients need to support 802.11k/v/r and may require additional setup. Performance may vary depending on the client device.
△Use of Wi-Fi 7(802.11be), Wi-Fi 6(802.11ax), and features including Multi-Link Operation(MLO), 320 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA, MU-MIMO and BSS Color requires clients to also support the corresponding features. The 320 MHz bandwidth is only available on the 6 GHz band. Simultaneously, the 160 MHz and 240 MHz bandwidths or the 320 MHz bandwidth might not be available on the 5 GHz band or the 6 GHz band, respectively, in some regions/countries due to regulatory restrictions. Double channel width and speed refer to 320 MHz compared to 160 MHz for Wi-Fi 6 mesh.
§2.5 Gbps internet speeds require compatible service plans and equipment. All WAN/LAN ports will operate as either WAN or LAN ports. Only one port can serve as a WAN port at a time.
*HomeShield includes the Free Basic Plan. Fees apply for the Pro Plan. Visit tp-link.com/homeshield for more information. Some features are under development and will be supported with subsequent software updates.
***The test was conducted in a 4,600 sq. ft. two-story villa with 5 bedrooms with an interior made up of drywall. The Deco BE65 was tested with 2×2 MLO-compatible clients. Home networking performance may vary, depending on the network's speeds, fiber or Ethernet access, WiFi interference, obstacles, walls, areas, and clients.
※4.2× faster Wi-Fi speed refers to the theoretical speeds of Wi-Fi 7 clients when connected to Deco BE65 compared with a 2×2 MIMO Wi-Fi 6 or Wi-Fi 6E mesh. Wi-Fi 7 clients need to support Multi-Link Operation(MLO) and the 6 GHz band to reach up to 10 Gbps when connected to the 5 GHz and 6 GHz bands of Deco BE65 simultaneously. 2×2 MIMO Wi-Fi 6 and Wi-Fi 6E mesh may only provide 2402 Mbps on the 5 GHz or 6 GHz bands separately.
※※4× Lower Latency refers to the latency improvement of Wi-Fi 7 mesh compared to Wi-Fi 6/6E mesh, based on laboratory test data. The test conditions had the same 5 GHz or 6 GHz single-frequency wireless interference and tested the maximum latencies of Wi-Fi 7 clients(with MLO turned on) connecting to the 5 GHz and 6 GHz bands of Deco BE65(with MLO turned on) simultaneously and to the 5 GHz or 6 GHz bands of a Wi-Fi 6/6E mesh(without the MLO function).
☆WiFi generations represent the wireless standard IEEE 802.11 a/b/g/n/ac/ax/be. Users may require an extra modem device that is compatible with their internet service provider to gain internet access.
